Dimmable T8 LED Tube Light 24W 1500mm Milky Cover Aluminum CE
AC120V
1. Description:
LED light tubes are also commonly known as LED light tubes, LED
fluorescent tubes, LED fluorescent tubes, and their light sources
use LEDs as light emitters. Traditional fluorescent tubes, also
known as fluorescent lamps, have a filament on both ends of the
lamp. The lamp tube is filled with traces of argon and thin mercury
vapor. The fluorescent lamp is coated on the inner wall of the
lamp. When the gas between the two filaments is conducting, it
emits ultraviolet rays. Causes the phosphor to emit visible light.
Due to the presence of "mercury", a heavy metal pollutant, the use
of scrapped fluorescent tubes poses serious environmental
pollution. LED lamps use light-emitting diodes as the light source,
which has higher luminous efficacy, more energy-saving, longer
service life, and more environmental protection. It is the best
product to replace fluorescent tubes at the current stage. LED
lamps and traditional fluorescent lamps in the dimensions of the
same size, there are T5 lamp, T8 lamp, T10 lamp, length 0.3m, 0.6m,
0.9m, 1.2m, 1.5m, 1.8m, 2.4m. .
2. T8 LED Tube Technical Data Sheet:
| Model number | AD-T8-1500mm-24W | AD-T8-1200mm-18W |
| Power | 24W | 18W |
| Input voltage | AC85-265V | AC85-265V |
| LED brand | Epistar | Epistar |
| LED light source | SMD2835 | SMD2835 |
| LED Quantity | 120pcs | 96pcs |
| Luminous efficiency | 100LM / W | 100LM / W |
| Total Lu men | 2400LM | 1800LM |
| Color temperature(K) | 3000K / 4000K / 6500K | 3000K / 4000K / 6500K |
| CRI(Ra) | 80 RA | 80 RA |
| LED Driver | Internal IC constant current non-isolated | Internal IC constant current non-isolated |
| Power factor | >0.9 | >0.9 |
| Shell material | Aluminum+PC | Aluminum+PC |
| Cover color | Milky / clear | Milky / clear |
| Lamp Size(mm) | L1500*Φ16 | L1200*Φ16 |
| IP rating | IP44 | IP44 |
| Life span(hour) | 30000 hours | 30000 hours |
| Warranty | 2 years warranty | 2 years warranty |
| Place of Origin | China Guangzhou city | China Guangzhou city |
3. Advantages:
1. High luminous efficiency: It adopts the internationally famous
brand independent patented LED manufacturing, and the lamp
efficiency is up to 115lm/w, which is 70% more energy than
traditional fluorescent lamps.
2. High color rendering: Color rendering index CRI=80, which can
truly reproduce the original bright colors of objects, creating a
comfortable light environment. Long life: The lamp tube is made of
glass tube material with good thermal conductivity, together with a
special high-heat-conductivity aluminum alloy radiator to ensure
that the LED junction temperature is always lower than 80°C, the
light failure is less than 8% in 10,000 hours, and the service life
is as long as 50,000 hours.
3. Safe and reliable: The power supply has multiple protection
functions such as lightning protection, overvoltage protection,
overcurrent protection, open circuit protection, and short circuit
protection, and meets the safety and regulatory requirements for
electromagnetic compatibility, harmonics, pressure resistance, and
insulation. The failure rate is <1/1000.
4. Applications:
Applicable to general lighting, office buildings, shopping malls,
restaurants, schools, homes, factories and other indoor lighting.
5. Contrast with traditional lamps:
Compared with incandescent bulbs, LED fluorescent lamps can save
more than 80% energy, and their service life is more than 10 times
that of ordinary lamps. It is almost maintenance-free. There is no
problem of replacing lamps, ballasts, and starters. It is about one
year. The cost savings can be changed back to the cost. The
eco-friendly semiconductor light source has soft light and pure
spectrum, which is beneficial to workers' vision protection and
physical health. The cold light source of 6000K gives people a
visually cool feeling, which helps to concentrate and improve
efficiency.
