Silicone G4 LED Light AC220V SMD3014 G4 G9 Base 360 Degree IC
Driver
1. Description:
G4 led lights are widely used in flat low voltage lamps, crystal
lamps, wall lamps, spotlights and other lamps. It has the
advantages of energy saving and long life. It is an ideal product
to replace the old lamps. The advantage of this product is that it
is only 1-3W, and its service life is about 30000 hours. And there
are white and warm white for choice. The overall use of the LED SMD
light source is low in heat and good in luminescent properties, and
is packaged with advanced silicone synthetic material. The
transmittance and heat dissipation are better. And reduce the risk
of transportation damage.
2. Advantages:
1. High efficiency and energy saving: the equivalent watt number
patch LED is 90% power supply than the traditional incandescent
lamp Festival, and is 60% light source than the halogen Festival.
Such
2. Super small size: G4LED light bead super small, let you install
worry free. The outside is coated with silicone, crystal clear,
waterproof and dust-proof, delicate appearance. Such
3. Luminescent angle: G4LED lamp beads 360 degree stereo
luminescence, especially suitable for all kinds of crystal beads,
shining brightly with crystal.
4. Low heat: the surface temperature of the patch LED lamp is about
60 degrees, and the ordinary lamp has a high fever compared with
the traditional halogen lamp. The patch LED lamp has a better heat
dissipation.
3. Detailed Technical Data:
| Model number | AD-G4-3014-48V | Power | 3W |
| Input voltage | AC220-240V | LED Brand | San'An |
| LED Type | SMD3014 | Total Lumen | 270LM |
| Chip Quantity | 48pcs | Color temperature(K) | 2800-6500K |
| Base | G9 | Material | Silicone |
| Size | 13*38mm | IP Rating | IP20 |
| LED Driver | IC constant current | Life span | 30000 hours |
| Certificate | CE RoHS EMC | Warranty | 2 years |
| Luminous efficiency | 100-110LM/W | CRI(Ra) | 80 |
3. Features:
1. Save Money Reduces labour and maintenance cost
2. Power consumption as low as 1-3W
3. Lower heating during operation
4. Environment-friendly and no UV or IR radiation;
5. Operating temperature: -25 to +55 degree Celsius
6. Lumen decay: 3 within 1000 hours. Then Lumens be stable.
7. Great energy-saving effect for G4 G9, save energy by over 70%
comparing with traditional lamps.
8. Long lighting distance and wide lighting areas.
5. G4 LED Light 220V Specification:
| AD-G4-3014-24V | G4 | SMD3014*24pcs | AC220-240V | 1.5W |
| AD-G4-3014-32V | G4 | SMD3014*32pcs | AC220-240V | 2W |
| AD-G4-3014-48V | G4 | SMD3014*48pcs | AC220-240V | 2.5W |
| AD-G4-3014-64V | G4 | SMD3014*64pcs | AC220-240V | 3W |
6. FAQ:
Q1. Is this led light universal type?
A1. Yes, it's plug&play type.
Q2. Can I have a sample order ?
A2: Yes, we favour the sample order to test and check quality.
Mixed samples are acceptable. 3-5 samples are for free, you just
bear the freight cost.
Q3. How do you ship the goods and how long does it take to arrive?
A3: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5
days to arrive. Airline and sea shipping also optional.
Q4: Can they fit for 12V and 24V cars?
A4: Yes, it can be suitable for all car models with constant IC
driver 12-24VDC.
Q5: How to process your Quality Control?
A5: All products must go through five checks before manufacturcing
process
Revelant material check before production
Full check after every individual process finished
Full check after production half-done
Spots check after production packed before shipping
