LED Slim Panel Light Recessed 175mm 18w Round Narrow Edge 90%
LIghting Area
1. Description:
Ado LED Slim Panel Light housing is different from the common panel
light, the housing ring is very narrow, narrow edge brings lighting
area is about 90%, more light from it, so the light output is
higher than same size panel light. Our 24w led panel light real
light output is about 90LM/W. LED Slim panel light is widely used
for many different places, it not only can replace traditional
lamps, but also it is very energy saving. Except this common
features, also it has 3 advantage which makes led slim panel light
becomes more and more popular. The advantages are long life,
conntrol ability and low comsumption.
2. Features:
1. This product has high light efficiency, lighting efficiency
reaches 90lm/w. Compared with conventional incandescent bulb, its
lighting efficiency enhances 10 times, and saves 95% energy, which
is economical and environmental friendly.
2. This product has several categories of wattage, optional
wattage:6w, 12w, 18w and 24w.
3. This product has several categories of color temperature,
optional color temperature: Daylight 6400K
or Warm white 2700K, and neutral white 4000K.
4. This product uses imported high quality LED chip, to guarantee
its good color rendering. The color rendering index reaches 80,
which is greatly improved than the general fluorescent lamp. It can
reflect the original color of the objects.
3. Advantages:
1. Use qualified high power SMD2835 LED, lower power consumption,
>80LM/W, no facula, no glare, uniform luminance.
2. Wide range of wattage available (AC100-240V).
3. Long life-span, small light decline rate, high CRI 85 is
available for 2700K and 3000K.
4. High class material, excellent heat dissipation.
5. Beautiful appearance, High brightness output.
4. Detailed Specification:
Size(D*H): 175*8mm
Cutout size: 155mm
Color Rendering Index: 80RA
Material: Aluminum(fixture)+PMMA(LGP)
Beam angle: 120°
IP rank: IP20
Operation temperature: -20℃~+60℃
Lighting Distance: 1-4meters
Mounting height: 2-3meters
Place of Origin: China
Approval mark: CE RoHs
Warranty: 2 years
Model: AD-EPR-PAL-18W
Input Voltage: AC85-265V
LED Chip: SMD2835
LED Type: 0.2W
LED Lumen: 24-26LM
LED Quantity: 90pcs
Power: 18W
LED Brand: Taiwan Epistar
CCT: 3000K / 4000K /6000K
Lumen: 1550LM ± 100 LM
Light guide plate(LGP) brand:Japan Mitsubishi
LGP thinkness: 3mm
LGP technology: Dot Laser
LGP light transmittance: 90%
Lifespan: (LM80) 30000H
Power factor: PF≧0.9
Driver :Smart IC Isolated constant current
Rated lifetime: 50.000 hours
5. Application:
Landscaping buildings, bridges, squares, sports centers, tunnels,
garden, subways, undergrounds, factories,clubs, hotels, stages,
parks, parking lots, plazas and art galleries.
6. Packing:
| Packing Size | 39*24*38cm |
| Packing Qty | 20pcs |
| Packing Gross Weight | 8.2kg |
| Packing Box | Colorbox |
| Packing Carton | Neutral |
| Shipping method | DHL / Fedex / TNT / Air Shipping / Sea Shipping |
| Shipping time | 3-7 days for express/air shipping, one month by sea |
| Samples Delivery Time | 3-5 days |
| Official Order Delivery Time | 16 work days |
