1. Technical Data Sheet:
Brand Name: Ado
Model Number: AD-EPS-PAL-6W
Power: 6W/12W/18W/24W
Color Temperature: 3000K,4000K,5000K
LED Chip Brand: Osram
LED Type: SMD2835
LED Quantity: 30pcs
LED Lumen: 22-24LM
LED Power: 0.2W
L70 life span: >50000Hrs
Beam Angle: 120 Degree
Dimmable: Customized
UGR: <19
Material: Aluminum+PC
2. Description:
Diammble led panel light is to use a dimmable driver to make led
panel light brightness can be adjusted by dimmer. We have 3
different dimmable led panel light. they are triac dimmable led
panel light, 0-10V dimmable led panel light, and Dali Dimmable LED
Panel Light. Triac is used more popular, because it is compatible
for the old dimmer, and don't need to change other connecting
wires. 0-10V dimmable solution could control several lamps, and
Dali dimmable is more intelligent, can control whole buliding's
lamp.
3. Advantages:
1. Slim LED panel light use isolated constant current power supply
,wide input voltage 85-264V/AC,
output voltage :30-40VDC, more safer.
2. There is no mercury & lead, etc. harmful substance which is bad
for environment.
3. It is energy saving, environmental protection and high
brightness.And it can save 65% electricity compared with
traditional grid lamp.
4. It can work instantly without flash,strobe and glare.
5. It won't be obstructed by wireless.
6. It is without infrared, ultraviolet and no heating effect.
4. Specification:
Light Source: LED
Item Type: Slim Surface Mounted LED Panel Lights
Warranty(Years): 2
Input Voltage(V): 85-265Vac
Lamp Power(W): 6
Lamp Luminous Flux(lm): 500
Lamp Luminous Efficiency(lm/w): 83
CRI (Ra>): 80
Size: 90mm
Working Temperature(℃): -20 - 40
Working Lifetime(Hour): 50000
Lamp Body Material: Aluminum
IP Rating: IP33, IP20
Certification: CE RoHS
Place of Origin: Guangdong, China (Mainland)
5. Other Model Items:
| Model | Shape | Color | Size | Lumen | Chip |
| AD-EPS-PAL-6W | Round | W,WW,NW | Φ90mm | ±540LM | SMD2835*30PCS |
| AD-EPS-PAL-12W | W,WW,NW | Φ145mm | ±1080LM | SMD2835*60PCS |
| AD-EPS-PAL-18W | W,WW,NW | Φ175mm | ±1620LM | SMD2835*90PCS |
| AD-EPS-PAL-24W | W,WW,NW | Φ225mm | ±2160LM | SMD2835*120PCS |
6. Application:
The Place you need high intensity and save energy, such as hotel,
meeting room, factory, office, house, shop mall, school, hospital
and library etc, then you can choose our super slim LED panel
light.
7. Features:
1. Fast&convenient installation
2. pretty & elegant and never unfading appearance
3. Excellent heat dissipation
4. Low maintenance cost
5. Enviromental Protection
6. Instant start, no flashing
8. Packing:
| Packing Size | 65*20*34cm |
| Packing Carton | Netural |
| Inner Box | Colorful |
| Packing Net Weight | 14.3kg |
| Packing Quantity | 100pcs |
| Packing Gross Weight | 15.8kg |
9. Delivery&Shipping:
1. Delivery time is 3-5days for samples, 7-10days for bulk order
2. Samples can be shipped by DHL/FedEx/UPS/TNT
3. Bulk order can be shipped by Sea
10. Why Choose Ado Lights?
A. Very Favorable and Attractive Price
B. High and Steady Quality
C. 100% New
D. Large Stocks (Stable Supply Ability)
E. All kinds of led slim panel light for your choice
F. Small Quantity allowed (Trial Order Also Welcomed)
H. Prompt Delivery
