6 Watt Recessed LED Slim Panel Light Aluminum 50,000 hours 4000K
80RA 500LM 3 years
1. Slim LED Panel Light Features:
1. Concise and ultra thin panel lamp design, effectively reduce the
ceiling height limit, high precision aluminum casting process, good
heat dissipation structure as well beautiful and generous.
2. Using high brightness SMD chip, the unique SMD side light
collocation guide plate make the light more and not dazzling.
3. Specially design of heat dissipation light source with high
quality constant-current IC driver.
4. Support Kelvin and brightness dimming.
5. Recessed, Wall Mounted and Suspended installations available.
6. TUV SAA C-tick PSE CE certificated.
2. Advantages:
1. Ultra-thin design
2. High luminous efficiency
3. Energy Saving
4. Easy Installation
5. Lower heating during operation
6. No mercury, environmental protection
7. Stable and intelligent led driver
8. High CRI to reflect the true color of the objects
3. LED Driver Technical Data:
Model: AD-D-4-6W
Type: Smart IC Isolated constant current
Dimmable: No
Input voltage: AC85-265V 50-60Hz
Output voltage: DC12-24V
Output Current: 300mA ± 5%
Power factor: 0.5
Tc: 85 ℃
Ta: 40 ℃
4. Quick Details:
Shape: Round
Beam angle: 120°
IP rank: IP20
Model: AD-EPR-PAL-6W
Input Voltage: AC85-265V
Power: 6W
Size(mm): φ90*H8mm
Rated lifetime: 50.000 hours
Housing Color: Powder painted white color
Housing Material: Aluminum
LED Brand: Taiwan Epistar
LED Chip: SMD2835
LED Power : 0.2W
LED Lumen: 24-26LM
LED Quantity: 30pcs
CCT: 3000K / 4000K /6000K
Lumen: 500LM
Color Rendering Index: 80RA
Life Span: 30,000 hours
Operation temperature: -20℃~+60℃
Driver Type: Smart IC Isolated constant current
Dimmable: No
Input voltage: AC85-265V 50-60Hz
Output voltage: DC12-24V
Output Current: 300mA ± 5%
Power factorLight guide plate(LGP) brand: Japan Mitsubishi
LGP thinkness: 3mm
LGP technology: Dot Laser
LGP light transmittance: 90%
LGP Material: PMMA: 0.5
5. Other Model Item:
| Model | Shape | Color | Size (D*H) | Cut-out Size |
| AD-EPR-PAL-6W | Round | W, WW, NW | Φ90*H8mm | 70mm |
| AD-EPR-PAL-12W | Φ145*H8mm | 125mm |
| AD-EPR-PAL-18W | Φ175*H8mm | 155mm |
| AD-EPR-PAL-24W | Φ225*H8mm | 205mm |
6. Application:
1. wall, ceiling, plat fond, sprung proof, integrated ceiling,
grille ceiling;
2. kitchen, office, hotel, hospital, cinema, market, shop, shower
room, corridor, lift, etc.
3 .car, counter, bar, gallery, museum.
7. Shipping:
We ship goods by UPS/DHL/FEDEX/TNT express which takes 3~ 5 days to
arrive, or by air cargo which takes about one week to arrive, or by
sea which takes about one month to arrive, depending on your actual
requirements.
8. Warranty:
Different quality products have different warranty, we have 2 years
warranty, 3 years warranty and 5 years warranty. If goods are
failure during our warranty period due to quality problems, please
send us the pictures and videos for the failure products, then we
will check the failure reasons. The new parts / accessories or
products will be replaced for free.
:
