Nickel wood white 6w 12w 18w dimmable led panel light recessed
4000K 80Ra SMD2835
1. 12w 18w led panel light specification:
| Model | AD-EPR-PAL-12W | AD-EPS-PAL-18W |
| Input Voltage | AC85-265V | AC85-265V |
| Power | 12W | 18W |
| Dimension(D*H) | 120mm*H20mm | 145mm*H35mm |
| Lumens | 1050-1200LM | 1700-1800LM |
| LED chip | SMD2835*60pcs | SMD2835*90pcs |
| CRI | 80Ra | 80Ra |
| CCT | CW NW WW | CW NW WW |
| Finish | White | Light Wood |
| Beam Angle | 120 degree | 120 degree |
| LED Brand | Epistar | Epistar |
| LED Driver | Isolated IC driver | Isolated IC driver |
| IP Grade | IP20 | IP20 |
| Material | Aluminum+PC | Aluminum+PC |
| Shape | Round | Round |
| Lifespan | 50000hours | 50000hours |
| Installation | Recessed | Surface Mounted |
| Emitting | side lighting | side lighting |
| Certificate | CE RoHS | CE RoHS |
| Warranty | 2 Years | 2 Years |
2. Description:
Dimmable led panel light are widely used for many places, the triac
dimmable led panel light is much common than 0-10V dimmable and
Dali dimmable led panel light. Only to change the normal driver to
triac dimmable led driver into the panel light, it is compatible to
the old dimmer which used for traditional lamps.
Dimmable led panel light installation is simple and does not
require additional wiring.
3. Application:
1. Restaurant / Hotel / Supermarket
2. Showroom / Meeting rooms
3. Factories & Offices
4. Commercial complexes / exhibition hall
5. School, Colleges & Universities
6. Hospital / Classrooms / Underground Park
7. Places where need energy saving and high color rendering index
lighting
4. Advantages:
1. Cost Effective
2. High Efficiency LED
3. Easy to install
4. Different color temperature
5. Size Optional
6. High CRI
7. High Luminous Efficiency
8. High Brightness
9. Ultra thin Lamp
10. Better heat dissipation
5. LED Chip Technical data:
Power: 12W
LED Chip: SMD2835
LED Type: 0.2W
LED Lumen: 24-26LM
LED Quantity: 60pcs
CCT: 3000K / 4000K /6000K
Lumen: 1550LM ± 100 LM
Color Rendering Index: 80RA
6. Detailed Information:
| Material: | Aluminum(fixture)+PMMA(LGP) |
| Beam angle | 120° |
| Operation temperature | -20℃~+60℃ |
| Lighting Distance | 1-4meters |
| Mounting height | 2-3meters |
7. Packing&Delivery
| Packing Size | 39*24*38cm |
| Packing Qty | 20pcs |
| Packing Gross Weight | 8.2kg |
| Shipping method | DHL / Fedex / TNT / Air Shipping / Sea Shipping |
| Shipping time | 3-7 days for express/air shipping, one month by sea |
| Samples Delivery Time | 3-5 days |
| Official Order Delivery Time | 16 work days |
8. Quality Control:
1. 100% of the lamps will be tested and passed all QC procedures
before shipping
2. Defective items will be compensated immediately or in next
order.
3. 500 times on and off testing after production finished.
4. Raw material full check before production.
5. 48 hours aging test after good is finnnished
