Brand Name : | ADO |
Model Number : | AD-SFL-50W |
Certification : | TUV CB CE FCC SAA RoHS |
Price : | Negotiation |
Payment Terms : | L/C, TT, Western Union, MoneyGram, Paypal |
Supply Ability : | 1000 pcs / day |
Delivery Time : | 3-5 days for samples, 7-15 days for mass order |
Waterproof 50W LED Flood Lights IP66 SMD5730 5000LM Aluminum 6000K
CE 80Ra
1. Description:
LED Floodlight is a point light that can be uniformly illuminated
in all directions. Its illumination range can be arbitrarily
adjusted and appears as a positive octahedral icon in the scene.
Floodlights are the most widely used light source in renderings,
and standard floodlights illuminate the entire scene. Multiple
floodlights can be used in the scene. It is made of
heat-dissipating aluminum, high-power LEDs, and LED driver. For the
led chips, it can be SMD type, also can be COB type. SMD type has
SMD5730 and SMD3030, COB type is using COB led chip, 10w, 30w and
50w. SMD type light luminous efficiency is higher than COB type,
which is used very widely at present.
2. Application:
Mainly used for tunnel lighting, outdoor flood lighting,
architectural decorative lighting, industrial place lighting,
sports centers and outdoor stadiums, ports, docks, etc.
3. Specification:
Model number | AD-SFL-50W | AD-SFL-100W |
Power factor | 0.92PFC | 0.92PFC |
Shell material | Aluminum | Aluminum |
Cover color | Milky / Cear | Milky / Cear |
Lamp Size(mm) | 250*160*50MM | 300*205*60MM |
IP rating | IP66 | IP66 |
Life span(hour) | 30000 hours | 30000hours |
Warranty | 3 years | 3 years |
Place of Origin | China | China |
LED Driver | Wide Voltage waterproof | Wide Voltage waterproof |
Power | 50W | 100W |
Input voltage | AC85-265V | AC85-265V |
LED brand | Epistar | Epistar |
LED light source | SMD5730 | SMD5730 |
LED Quantity | 50pcs | 100pcs |
Total Lumen | 5000LM | 10000LM |
Luminous efficiency | 100LM/W | 100LM/W |
Color temperature(K) | 3000-6500K | 3000-6500K |
CRI(Ra) | 80Ra | 80Ra |
4. Technical Data:
Lamp Materials: Aluminum heat sink+tempered glass
Fixture Color: white / black / grey
Working Temperature: -20℃~ 60℃
LED Driver: IP66 Wide Voltage Waterproof
5. Features:
1. Long Life Span and Low Consumption
2. High Luminous Efficiency and high CRI
3. Stable Performance and Flicker Free
4. Good heat dissipation and Energy Saving
5. Easy Install and low maintenance
6. Green and environmental
6. Packing:
Model | AD-SFL-50W | AD-SFL-100W |
Inner Box Size | 28*6.5*19cm | 33.5*7*22.5cm |
Packing Size | 60*39*21.5cm | 43*36*25cm |
Packing Quantity | 10pcs | 5pcs |
Product net weight | 1.45kg | 2.3kg |
Product gross weight | 1.6kg | 2.5kg |
Packing net weight | 14.5kg | 11kg |
Packing gross weight | 17kg | 13.5kg |
7. Installation and use:
The waterproof led flood light can be installed individually, or
they can be combined in multiple lamps to be mounted on a pole of
more than 20 meters to form a high pole lighting device. Besides
the features of beautiful appearance, centralized maintenance, and
reduced poles and floor space, the biggest advantage of this kind
of device is its strong lighting function. When the light is
projected from a height, the environment has a high spatial
brightness and a large light coverage, giving a feeling similar to
daylight, and therefore has higher lighting quality and visual
effects. In order to meet the minimum safety requirements for
outdoor use, the enclosure protection of the led floodl light shall
be IP×3 (open type). In order to improve the durability of the
lamps and reduce the maintenance workload, people are paying more
and more attention to the development of closed floodlights with
high one-time investment costs. The enclosure protection class is
IP66.
![]() |
