    Aluminum Led Flat Panel Light 60cm 2ft Surface Mounted 90ra In Pure White

    Ask Lasest Price
    Brand Name : ADO
    Model Number : AD-PAL66-48W
    Certification : CE ROHS TUV UL
    Price : Negotiation
    Payment Terms : PayPal, Western Union, T/T, L/C
    Delivery Time : 5 - 8 work days
    • Product Details
    • Company Profile

    Aluminum Led Flat Panel Light 60cm 2ft Surface Mounted 90ra In Pure White

    48W LED Flat Panel Light 60cm 2ft Aluminum Sliver Surface Mounted Pure White 90Ra

    1. Light Guide Plate Details:


    BrandJapan Mitsubishi
    MaterialPMMA
    Height3mm
    Light Transmittance90%
    TechnologyLaser Dot


    2. Packing Information:


    Inner Box Size:66.5*64*4.5cm
    Product Net Weight:3.6kg
    Packing Size:68.5*65.5*24.5cm
    Packing Quantity:5pcs
    Packing Gross Weight:18.5kg

    3. Specification:


    1. Brand: Ado lighting (or given by buyer)
    2. Power: 48W
    3. Input Voltage: 85-265V, 50/60Hz
    4. Aluminum frame + Aluminum LED plate + PMMA light guide plate
    5. IP Rate: IP44
    6. Lumen Efficiency: 100lm/w
    7. Driver output: DC42V, 017A
    8. CCT: 2700-6500K
    9. Power Factor: >0.95;
    10. THD: <20%

    11. CRI(Ra): >80
    12. Energy saving up to 90%
    13. 3 years warranty.
    14. Working Lifespan: 50000 hours

    15. Working Temperature: -20~+40 degree


    4. Important Product Material:


    1. LM-80 certified LED with high brightness and low decay
    2. TUV SAA CB ENEC certified Driver, very stable and long life
    3. UL Listed led lighting guide plate from Japan Mitsubishi, good light transmittance.
    4. Famousl brand LED: Osram, Samsung, Soul. LG. Epistar
    5. Internaitonal Brand Driver: Tridonic, Meanwell. Lifud


    5. Advantages:
    1. LED Chip: Latest imported SMD4014 or SMD2835 led chips for ensuring higher ;umen with LM80, low decay, long lifespan
    2. LED Driver: PF>0.9, flicker free, CE passed driver, stable isolated IC constant current project
    3. Light Guide Plate: Adopt Japan Mitsubishi PMMA LGP, 3mm thickness, uniform lighting, no dark area, soft lighting effect, 90% light transmittance.
    4. Slim Design: panel light height is only 11mm, perfect slim design
    5. Aluminum Housing: Aluminum material fixture is good for heat dissipation.
    6. Diffuser: Taiwan CHIMEI supplied material for diffuser, better glare control

    6. Why Choose Ado Flat LED Panel Light?


    1. Professional sales team and workers and engineers

    2. Rich Experiences: 5 years' research and development in LED panel light;

    3. Key components: Light guide plat is from Japan, epistar chip from Taiwan, LED driver from USA

    4. Good Quality control: ISO9000 quality system and IBM internal quality system are carried out in the factory.

    5. Warm Services: Mothly and annual follow-up for your order and solve problems

    6. Professional Solutions: Suitable LED panel lighting solutions can be provided free of charge, save your cost and expenditure.

    7. First-class Equipments: Dust-free workshop, and top optical lab for LED panel light test.

    8. OEM & ODM services: Your logo on the product and packing as well as customized design can be acceptable.

    9. 3 years warranty and 5 years warranty for led panel lights.
