LED Slim Panel Light 6w 90mm Recessed Mounted Warm White IP20 PMMA
LGP
1. Specification:
| Model | Size:Face/cutout | Voltage | KV Surge | Lumen | Power Factor |
| AD-DP-6W | 90/75 | AC85-265V | 2.5KV | 65LM/W | 0.60 |
| AD-DP-12W | 120/105 | AC85-265V | 2.5KV | 80LM/W | 0.90 |
| AD-DP-18W | 170/155 | AC85-265V | 2.5KV | 90LM/W | 0.90 |
| AD-DP-24W | 225/205 | AC85-265V | 2.5KV | 90LM/W | 0.90 |
| AD-DP-S6W | 90*90/75*75 | AC85-265V | 2.5KV | 65LM/W | 0.60 |
| AD-DP-S12W | 120*120/105*105 | AC85-265V | 2.5KV | 80LM/W | 0.90 |
| AD-DP-S18W | 170*170/155*155 | AC85-265V | 2.5KV | 90LM/W | 0.90 |
| AD-DP-S24W | 225*225/205*205 | AC85-265V | 2.5KV | 90LM/W | 0.90 |
2. Description:
Our This DP series slim led panel light advantage is that the
lighting is direct, not side emitting, other products information
are the same, they are assemble by aluminum housing, led chips, led
drivers and other components. Please see the following descerption
about the important components which consist of slim led panel
light.
1. Surface Treatment: Die casting aluminum with anti-fading satis
powder coating
2. Heat Sink: Die-casting aluminum body with strip pattern provide
better effect for heat transmitting
3. Ultra Bright Chips: High lumen SMD2835 output up to 26LM/pcs SMD
chip, high CRI, low decay
4. Smart IC Driver: Intelligent constant current IC driver, stable
project, long lifespan assurance
5. Slim design, good looking, easy installation, low maintanence
3. Specification:
Light Source: LED
Item Type: LED Slim Panel Lights
LED Light Source: SMD2835
Warranty(Years): 2
Input Voltage(V): AC85-265V
Lamp Power(W): 18W
Lamp Luminous Flux(lm): 1600LM
Lamp Luminous Efficiency(lm/w): 90
CRI (Ra>): 80
Color Temperature(CCT): Pure White
Working Temperature(℃): -20 - 85
Working Lifetime(Hour): 30000
Lamp Body Material: Aluminum Alloy
IP Rating: IP20
Certification: CCC, CE, RoHS, SAA, BIS
Place of Origin: Guangdong, China (Mainland)
Shape: Round Shape
Installation: Reccessed
4. Installation information:
| Insulation grade | II |
| Energy-saving level | A PLUS |
| Lighting Distance | 1-4meters |
| Mounting height | 2-3meters |
5. Feature:
A. Power: 6W 12W 18W 24W
B. Size: 90mm 120mm 170mm 225mm
C. Shape: Round Square
D. Installation: Recessed
E: Dimmable / non Dimmable
F. CCT: 3000K 4000K 6000K
G. CRI: 80Ra
H: Fixture color: White/ Black
6. Warranty Issues:
Our product warranty is 2 years, under normal use conditions, our
led lamps quality assurance is based on
the product's correct installation, use and maintenance; due to
improper installation, use and maintenance
of products, and the product damage, does not belong to the scope
of the guarantee period, the company
will choose repair, replacement (parts) or replacement of new
products, etc. Exceeding the quality
guarantee period will be appropriate charged for materials and
labor costs.
If products are failure because of the quality, we will send you
new good products for free, but you need to send us the failure
products pictures and video, then we can check the failure reasons.
