Recessed Anti-Glare LED Panel Light 22w Round SMD2835 3000K 80Ra
1. Technical Data and Features:
| Power | 5W | 9W | 12W | 16W | 22W |
| Shape | Round | Round | Round | Round | Round |
| Ring diameter | ¢90mm | ¢120mm | ¢140mm | ¢170mm | ¢220mm |
| Hole size | Φ75mm | Φ105mm | Φ125mm | Φ155mm | Φ205mm |
| Color | warm white 3000K neutral white 4000K cool white 6500K |
|
| LED | SMD2835 |
| LED QTY | 25LED | 45LED | 60LED | 80LED | 110LED |
| PCS/Carton | 50 PCS | 50 PCS | 20 PCS | 20 PCS | 20 PCS |
| Carton Size (cm) | 60*20*25.5 | 75*20*31.5 | 35.5*20*34 | 41.5*20*40.5 | 51.5*20*50.5 |
| CBM/ CTN | 0.0306 | 0.04725 | 0.02414 | 0.033615 | 0.052015 |
| Anti-Glare LED Panel Light Features |
| Input Voltage | AC85-265V | Lifespan | 50000hours |
| Luminous Flux | 80-90LM/W | Certificate | CE RoHS |
| Finish | White | Warranty | 2 Years |
| Beam Angle | 120 degree | Market | Europe. USA |
| LED Brand | Epistar | Finish | White |
| LED Driver | Isolated IC Constant smart driver | Beam Angle | 120 degree |
| IP Grade | IP20 | CRI | 80Ra |
| Material | Aluminum+PC | Installation | Recessed Mounted |
2. Advantages:
1. This anti-glare led panel light use Epistar led chips SMD2835
which is from Taiwan. The lumen is 24-26LM, power is 0.2W. Whole
lamp lumen efficiency is about 80-90Lm/W, light is very soft and
uniform. The led chip CRI is more than 80ra, which can reflect the
objects true colors, and no glare at all. life span is more than
50000 hours.
2. The led driver is isolated IC constant current project, it is
very safe and intelligent. The voltage is from AC85-265V, which is
suitable for world's voltage, widely used for many different
countries. The led driver's quality is very improtant for a lamp's
quality. High quality led drivers can make the led lamps life span
is much longer than normal led driver.
3. It is recessed mounted installation, which is very easy to
replace the old panel light. Just to make sure the ceiling cutout
size is the same as ours. we have many different sizes, they are
75mm, 105m, 125mm, 155mm,175mm and 205mm, you could choose the size
which can meet your original cutout size. can met your diffferent
needs.
3. Customized service:
We peovide many different services which can meet customer's
different quality requirements.
1. LED Chips Brand: If you want to use Chinese San'an led chips or
imported Osram led chips or some other famous brands, all we can
provide for you. It is based on your needs, and the CRI such as
70Ra, 80Ra or 90Ra, and the luminous efficiency 80Lm/W, or 100LM/w,
these special requirements all can be customized according to your
request.
2. LED drivers Brand: Lifud led driver, led driver, or dimmable led
driver. we can change the drivers to meet different customer's high
qualiy needs, Lifud led driver will have 3 years warranty, led
driver can has 5 years warranty.
3. Customzied label / box / carton: For bulk order, some customers
need to use their own company logo, we can ask the paper printing
box factory to design the customized label(box, carton). small
quantity will cost some extra cost. Big quantity order could be
free charged.
4. Customized housing color: This anti-glare common color is white,
but we could customize black color if you need. Or other sliver
color for some special needs, all your needs could be satisfied.
4. Trade Terms:
1. Sample can be delivered in 3 days
2. Private labeling and distributorships are offered.
3. Our own design and product development is without any patent
problem.
4. Payment: 30% deposits before production, 70% balance to be paid
before deliver
5. You are welcome to visit our lighting showroom and factory.
6. Discount are offer base on quantity.
