3w 5w 7w MR16 GU10 E27 LED Spot Bulbs white housing 220V 12V 3000K
4000K
1. 5W MR16 and GU10 LED Spot Bulb Specification:
| Model number | AD-SP05-5W | AD-SP05-5W |
| Power | 5W | 5W |
| Lumen | 450LM | 450LM |
| Input voltage | AC220-240V | AC/DC12V |
| Base | GU10 | MR16 |
| LED brand | Epistar | Epistar |
| LED light source | 1W | 1W |
| LED Quantity | 5pcs | 5pcs |
| Beam Angle | 45 degree | 45 degree |
| LED Type | SMD3030 | SMD3030 |
| LED Lumen | 110LM/W | 110LM/W |
| Color temperature(K) | 2700K 4000K 6000K | 2700K 4000K 6000K |
| CRI(Ra) | 80Ra | 80Ra |
| Shell material | Aluminum | Aluminum |
| Lamp Size(mm) | 50*53mm | 50*57mm |
| IP rating | IP20 | IP20 |
| Life span(hour) | 30000 hours | 30000 hours |
| Warranty | 2 years | 2 years |
| Place of Origin | China | China |
| LED Driver | IC constant current | IC constant current |
| Dimmable | Yes | Yes |
| Certificate | CE RoHS | CE RoHS |
2. 3W, 5W, 7W LED Spot Bulb Specification:
| Model | AD-SP05-3W | AD-SP05-5W | AD-SP05-7W |
| Power | 3W | 5W | 7W |
| Base | GU10 E27 MR16 |
| Voltage | AC 85-265V DC / AC12V |
| LED Chip | SMD3030 | SMD3030 | SMD3030 |
| LED Quantity | 3pcs | 5pcs | 7pcs |
| CCT | WW: 2700-3000K NW: 4000-4500K CW: 6000-6500K |
| LED Power | 3*1W | 5*1w | 7*1w |
| Lumen | 240-270LM | 400-450LM | 560-630LM |
| Size | Φ49*57mm | Φ49*57mm | Φ49*75mm |
| Beam Angle | 25° 45° |
3. Features:
| Voltage | AC220V, AC110V, AC85-265V, DC12V, AC12V |
| Power | 3W, 4W, 5W, 7W |
| Color temperature | 2700-3000K, 4000-4500K, 6000-6500K |
| LED Type | COB 1W, 3W, 5W and 7W, SMD5050, SMD2835 and SMD3030 |
| CRI | 80Ra or 90Ra |
| Dimmable | Dimmable and non dimmable version are optional |
| Beam Angle | 30 degree, 38 degree, 45 degree, 60 degree, 120 degree |
| Housing color | white, black, grey, sliver |
| Base | GU10, MR16, E27, GU5.3 |
| Material | Aluminum, Ceramic, PC. |
| Packing | Neutral white box, Neutral color box, Customize box. |
| Warranty | 2 Year warranty and 3 years warranty |
4. Application:
LED Spot Bulb is widely used in:
1. Interior display lightings such as shop displays, jewellery shop
windows, restaurants, restaurants, etc.; exhibition halls, art
halls, museums, offices, reading rooms, clothing stores, etc.;
large-scale decorative lights; disco, bar, card, OK, etc. Lighting;
jewelry, gold and silver jewelry and fashion lighting;
2. Local lighting: lighting used in corridors, toilets, garages,
parking lots, security lights used in factories, residential areas,
security lights, night lights, lights, night lights used in the
room, and lights;
3. Decorative lighting: suitable for construction, home decoration,
window, counter lamp and other decorations.
5. FAQ:
1. Can i have dimmable led spot light?
Yes, we offer dimmable led spotlight bulbs, and it is triac
dimmable.
2. Can i have GU5.3 base?
Yes, GU5.3 voltage is AC220V, please don't use it on DC12V voltage.
3. What's the material of the led spot light bulbs?
Our led spotlight bulbs material is aluminum, it is good for heat
dissipation, also we can make PC housing.
4. Do you provide RGB LED Spot Light?
Of course we can provide RGB spot bulbs, also it is with the RGB
controller, can change many many different colors by using the
controller.
5. Can i have dimmable led spot light with voltage AC85-265V?
I am sorry no, if dimmable, the driver voltage is AC220-240V or
AC100-130V. If non dimmable, the driver can be wide voltage
AC85-265V.
6. Why Choose Ado LED Spot Bulbs?
1. Market new and special design products
2. Good quality material to assemble the led spot bulbs.
3. Instrict QC department to inspect and test all the products
before shipping
4. 48 hours products aging test with on and off.
5. Professional workers to produce led spot bulbs without mistakes.
6. Good after-sales services to follow up your orders
7. Friendly international salesman to solve all of your problems
