LED Spot Bulbs 5W MR16 Dimmable DC12V Warm White Aluminum 3000K
80Ra 500LM
1. Description:
Our this item number AD-SP101 is sliver houing with 1W high power
led chip, housing material is aluminum, which is good for heat
dissipation. The led chip is Taiwan Epistar brand with 80RA, power
can make 3w, 5w and 7w, luminous efficiency is about 80-90LM per
wattage. And the base can make MR16, E27 and GU10, this led spot
light beam angle is 60 degree. Dimmable version and non dimmable
version are optional.
2. LED Spot Light Specification:
Input Voltage: AC85-265V
Input Power: 5W
LED Type: 1pcs*5W
Luminous Flux: 400-500LM
Color Temperature: 2700K-5000K
CRI: 80Ra (90Ra can customize)
Lifetime: 40,000-50,000hours
IP Rating: IP20
Housing Color: Sliver
Beam angle : 60° / 45° / 30°
3. Technical Data:
| Model number | AD-SP01-5W |
| Power | 5W |
| Lumen | 500LM |
| Input voltage | DC12V |
| Base | MR16 |
| LED brand | Epistar |
| LED light source | 5W |
| LED Quantity | 1pcs |
| Beam Angle | 60 degree |
| LED Type | 1W high power led |
| Certificate | CE RoHS |
| LED Lumen | 90-100LM/W |
| Color temperature(K) | 2700K 4000K 6000K |
| CRI(Ra) | 80Ra |
| Shell material | Aluminum |
| Lamp Size(mm) | 50*85mm |
| IP rating | IP20 |
| Life span(hour) | 30000 hours |
| Warranty | 2 years |
| Place of Origin | China |
| LED Driver | IC constant current |
| Dimmable | Yes |
4. Quick Details:
A. 3W Replacing 25W halogen lamp
B. High efficient LED light source--- COB LED Chip from Taiwan
Epistar
C. With GU10 / MR16 /E14 / E27 different lamp bases
D. Color rendering index of 80Ra and 90lm/W
E. Long life properties--lowers maintenance costs by reducing
re-lamp frequency
F. Warranty 2 years
G. CE RoHS EMC LVD certificate approved
H. Long life span with 30000 hours
5. Application:
LED Spot bulbs light are suitable for indoor lighting in hotels,
bars, western restaurants, cafes, home interiors, etc. They can
directly replace the original ordinary fluorescent lamps and have
higher brightness.
6. Different base dimension:
E14 : 50mm( diameter) X78mm(length)
E26 : 50mm( diameter) X 62mm( length)
E27 : 50mm (diameter) X 63.2mm (length)
MR16 : 50mm( diameter) X 53mm( length)
GU10 : 50mm ( diameter) X 62mm ( length)
GU5.3 : 50mm ( diameter) X 63mm ( length)
7. RFQ:
Q1. Are you a manufacturer or a trading company?
A1. We are a factory in Guangzhou, with
OEM&ODM&Customization available.
Q2. Do you have the ability to do independent research and
development?
A2. Five people in the engineering department support our company
to do independent research. And willlaunch new products on a
regular basis.
Q3. Can you give us a favorable discount ?
A3. Of course, a favorable discount will be offered if the quantity
is sizable.
Q4. Are your products conforming to our standards?
A4.Yes, our products pass the testings as you require, e.g.:CE,
RoHS,etc.
Q5. How do you control the quality ?
A5. We control the product quality by IQC, three tests on
production lines, and 100% aging testing before packaging.
